By Manny Fernandez

September 3, 2026

FortiGate Port Reference: Every Port for FAZ, FMG, RADIUS, CAPWAP, and the Rest of the Fabric

Every FortiGate deployment eventually runs into the same wall: a firewall change request, a cloud security group, or an MSSP’s out-of-band management network needs a specific port opened, and the answer is scattered across a dozen different Fortinet documents. This is the reference I wish existed as a single page. It’s organized by the peer device or service the FortiGate is talking to, with direction called out from the FortiGate’s point of view, so you can hand a single table to a network team and move on.

A note before you dive in: these are the default, documented ports as of the current FortiOS Ports and Protocols guide. Several of them (FSSO on TCP/8001, the Security Fabric port on TCP/8013, the RADIUS server port itself) are configurable per object, so treat the table as the factory default, not gospel, and confirm against your own config with show full-configuration before you finalize a change request.

How to Read This

Direction is always relative to the FortiGate. “Outgoing” means the FortiGate initiates the session toward the peer. “Incoming” means the peer initiates toward the FortiGate. A few protocols (FGFM being the classic example) can run in either direction depending on which side sits behind NAT, so those are called out explicitly.

Quick Reference

Peer Purpose Direction Protocol/Port
FortiAnalyzer Syslog, OFTP, registration, quarantine, log & report Outgoing TCP/514
FortiManager FGFM management (IPv4) Either TCP/541
FortiManager FGFM management (IPv6) Either TCP/542
FortiManager AV/IPS push Incoming UDP/9443
FortiManager Log & report Outgoing TCP or UDP/514
RADIUS server Authentication (Access-Request) Outgoing UDP/1812
RADIUS server Accounting Outgoing UDP/1813
RADIUS (RFC 5176 DAS/CoA) Dynamic authorization, disconnect Incoming UDP/3799
FortiAuthenticator RADIUS disconnect Incoming TCP/1700
FortiAuthenticator LDAP / PKI authentication Outgoing TCP or UDP/389
FortiAuthenticator FSSO Outgoing TCP/8000
FortiAuthenticator SCEP Outgoing TCP/80, TCP/443
FortiAuthenticator CRL download Outgoing TCP/80
FortiAuthenticator Policy auth via captive portal Incoming TCP/1000
FortiAP CAPWAP control tunnel Both UDP/5246
FortiAP CAPWAP data tunnel Both UDP/5247
FortiSwitch FortiLink management channel Both TCP/443
FortiGuard AV/IPS update Outgoing TCP/443, TCP/8890
FortiGuard Queries (web/app rating) Outgoing UDP/53, UDP/8888, TCP/53, TCP/8888, TCP/443
FortiGuard DNS Filter SDNS queries Outgoing UDP/53, TCP/853
FortiGuard Registration Outgoing TCP/80
FortiGuard Alert email, virus sample submission Outgoing TCP/25
FortiGuard Management, firmware, FTM, licensing Outgoing TCP/443
FortiClient Remote IPsec VPN Incoming UDP/500 (IKE), IP 50 (ESP), UDP/4500 (NAT-T)
FortiClient Remote SSL VPN Incoming TCP/443
FortiClient / EMS SSO Mobility Agent, FSSO Incoming TCP/8001
FortiClient EMS Compliance, Security Fabric Incoming TCP/8013
HA peer Heartbeat Both Ethertype 0x8890, 0x8891, 0x8893
HA peer Synchronization Both TCP/703, UDP/703
FortiSandbox OFTP (submission and verdict) Outgoing TCP/514
FortiGate Cloud Registration, log & report, syslog Outgoing TCP/443
FortiGate Cloud OFTP Outgoing TCP/514
Admin / browser Web Admin GUI Incoming TCP/80, TCP/443
SSL VPN client SSL VPN Incoming TCP/443

FortiAnalyzer (FAZ)

FortiGate ships logs to FortiAnalyzer, handles registration, and pushes quarantine and log-and-report data all over one port: TCP/514, outgoing. This is the single most common gotcha on this whole list, so it gets its own callout below.

Purpose Direction Protocol/Port
Syslog, OFTP, registration, quarantine, log & report Outgoing (FortiGate to FAZ) TCP/514
Gotcha
TCP/514 here is not plaintext syslog. It’s Fortinet’s OFTP (Optimized Fabric Transfer Protocol) layered on top, and it’s encrypted by default once the device is registered. If a firewall rule was written by someone who assumed “syslog is UDP/514” and opened the UDP port instead, FAZ registration will fail and logs will never arrive, with no obvious error pointing at the port. Open TCP/514, not UDP/514, for FAZ.

FortiManager (FMG) and FGFM

The FortiGate-to-FortiManager protocol (FGFM) is what carries device registration, config push, revision history, and firmware/FortiGuard push. Port 541 is FGFM’s IPv4 default; 542 handles the IPv6 variant.

Purpose Direction Protocol/Port
FGFM management (IPv4) Either TCP/541
FGFM management (IPv6) Either TCP/542
AV/IPS push Incoming (FMG to FortiGate) UDP/9443
Log & report Outgoing TCP or UDP/514
FortiGuard queries relayed through FMG Outgoing UDP/53, UDP/8888, TCP/80, TCP/8888
Gotcha
FGFM’s directionality depends on your topology, and this is the one clients get wrong most often on change requests. In a typical NOC/MSSP layout, FortiManager sits on a routable IP and initiates TCP/541 toward each managed FortiGate. If instead your FortiGate is on the public internet and FortiManager sits behind NAT (or vice versa), the FortiGate initiates outbound to FortiManager on 541 instead. Know which device is behind NAT before you write the rule, or you’ll open the port on the wrong side.

RADIUS, LDAP, and FortiAuthenticator

FortiGate as a RADIUS client uses the modern IANA-assigned ports, not the legacy Livingston ports many older NAS devices still default to.

Purpose Direction Protocol/Port
RADIUS authentication (Access-Request) Outgoing UDP/1812
RADIUS accounting Outgoing UDP/1813
LDAP / PKI authentication Outgoing TCP or UDP/389
FortiAuthenticator RADIUS disconnect Incoming TCP/1700
RADIUS Dynamic Authorization / CoA (RFC 5176) Incoming UDP/3799
FSSO Outgoing TCP/8000
SCEP Outgoing TCP/80, TCP/443
CRL download Outgoing TCP/80
Policy authentication via captive portal Incoming TCP/1000
External captive portal Both TCP/443
Gotcha: legacy ports
RFC 2865/2866 standardized RADIUS on UDP/1812 (auth) and UDP/1813 (accounting), but a huge number of NAS appliances in the field still default to the pre-standard UDP/1645 and UDP/1646. FortiGate’s RADIUS server object lets you set the port explicitly under config user radius, so if authentication silently fails against an older RADIUS server, check the port on the server object before you assume it’s a firewall problem.
Gotcha: two different “disconnect” mechanisms
Don’t conflate these. FortiAuthenticator’s own RADIUS disconnect feature listens on TCP/1700 into the FortiGate. The generic RFC 5176 Dynamic Authorization / Change of Authorization mechanism (used by plenty of non-Fortinet RADIUS servers to force a session disconnect or re-auth) is UDP/3799. If you’re integrating with a third-party RADIUS server that supports CoA, you almost certainly want 3799, not 1700.

CAPWAP (FortiAP)

The wireless controller function on a FortiGate manages FortiAP units over CAPWAP, split into a control channel and a data channel.

Purpose Direction Protocol/Port
CAPWAP control tunnel Both (FortiGate and FortiAP) UDP/5246
CAPWAP data tunnel Both UDP/5247
Gotcha
UDP/5247 only carries client traffic when the AP is running in tunnel mode, where wireless client packets get encapsulated back to the FortiGate for local switching. An AP in bridge mode switches client traffic locally at the AP and never uses 5247 for user data, so seeing control-channel traffic on 5246 but nothing on 5247 is expected behavior for a bridge-mode SSID, not a broken tunnel.

FortiLink (FortiSwitch)

FortiLink is the management protocol between a FortiGate and the FortiSwitches it manages. Unlike CAPWAP, it doesn’t get its own dedicated port; it rides the switch’s standard HTTPS administrative port.

Purpose Direction Protocol/Port
FortiLink management channel Both TCP/443
Gotcha
This matters most when you’re extending FortiLink over a routed connection instead of a direct Layer 2 uplink (regional office to a FortiGate over MPLS, for example). Because it’s just TCP/443, it’s easy to assume it will pass through any standard HTTPS-permitting rule, but the FortiSwitch on the far end still needs a Layer 3 path back to the FortiGate’s FortiLink interface, and the switch must be explicitly set to fortilink management mode before it will originate the session.

FortiGuard

FortiGuard covers AV/IPS signature updates, web and app rating lookups, DNS Filter queries, licensing, and firmware delivery. Most of this fans out across a handful of ports depending on which service is asking.

Purpose Protocol/Port
AV/IPS update TCP/443, TCP/8890
Cloud App DB TCP/9582
FortiGuard queries (web/app rating) UDP/53, UDP/8888, TCP/53, TCP/8888, TCP/443
DNS Filter SDNS queries UDP/53, TCP/853
Registration TCP/80
Alert email, virus sample submission TCP/25
Management, firmware, SMS, FTM, licensing, policy override TCP/443
Central management, analysis TCP/541
Gotcha
FortiGuard queries default to UDP/8888, which trips up a lot of egress rules that only permit standard DNS (UDP/53) and web (TCP/443) outbound. If web filter or app control categorization is silently failing while everything else works, UDP/8888 outbound to the FortiGuard Distribution Network is the first thing to check. FortiGate reaches the FDN through update.fortiguard.net, service.fortiguard.net, and support.fortinet.com when a proxy is configured, so allow those FQDNs alongside the raw ports if your egress control is FQDN-based.

FortiClient, FSSO, and EMS

Purpose Direction Protocol/Port
Remote IPsec VPN access Incoming UDP/500 (IKE), IP protocol 50 (ESP), UDP/4500 (NAT-T)
Remote SSL VPN access Incoming TCP/443
SSO Mobility Agent, FSSO Incoming TCP/8001 (default, customizable)
Compliance and Security Fabric (EMS) Incoming TCP/8013 (default, customizable)

HA (Heartbeat and Synchronization)

Purpose Protocol/Port
HA heartbeat Ethertype 0x8890, 0x8891, 0x8893
HA synchronization TCP/703, UDP/703
Unicast heartbeat (Azure) UDP/730
DNS (Azure) UDP/53
Gotcha
HA heartbeat traffic runs at Layer 2 over a proprietary ethertype, not a TCP/UDP port at all. If you’re trying to firewall or filter HA heartbeat traffic on a switch between cluster members (which you generally shouldn’t be doing on the dedicated HA link in the first place), you’re looking for ethertype ACLs, not an access list keyed on IP protocol and port.

FortiSandbox

Purpose Direction Protocol/Port
OFTP (file submission and verdict return) Outgoing TCP/514

FortiGate Cloud

Purpose Direction Protocol/Port
Registration, quarantine, log & report, syslog Outgoing TCP/443
OFTP Outgoing TCP/514
Management Outgoing TCP/541
Contract validation Outgoing TCP/443

Miscellaneous

Purpose Direction Protocol/Port
Web Admin GUI Incoming TCP/80, TCP/443
SSL VPN Incoming TCP/443
Policy override authentication Incoming TCP/443, TCP/8008, TCP/8010
Policy override keepalive Incoming TCP/1000, TCP/1003
AeroScout vendor port Incoming UDP/1144
External captive portal auth (FortiAP bridge mode) Incoming UDP/2000
Security Fabric Both TCP/8013 (default, customizable), UDP/8014

Verifying and Restricting These Ports from the CLI

A few commands worth keeping handy once the rules are in place.

Check whether a RADIUS server is actually reachable and authenticating, independent of any policy that might be silently blocking it:

diagnose test authserver radius <server-name> pap <username> <password>

Confirm FortiSwitch units are attached over FortiLink and see their negotiated state:

get switch-controller managed-switch

Check live sessions to FortiAnalyzer to confirm the OFTP channel is actually up, not just configured:

diagnose sys session filter dport 514
diagnose sys session list

Lock down FGFM to a specific FortiManager IP instead of leaving it open to any source, using a local-in policy:

config firewall local-in-policy
    edit 1
        set intf "wan1"
        set srcaddr "fmg-mgmt-ip"
        set dstaddr "all"
        set action accept
        set service "FGFM"
        set schedule "always"
    next
end

The Bottom Line

Most of these ports are stable across FortiOS versions and have been for years, but “stable” isn’t the same as “guaranteed,” and some of them (FSSO, Security Fabric, the RADIUS server port itself) are configurable per object rather than fixed. Before you submit a firewall change request built off this table, confirm against your own show full-configuration output and against the Ports and Protocols document for the specific FortiOS version you’re running. Treat this page as the fast path to the right answer, not the final word.
